large capacity cryogenic pressure vessel oxygen storage tank

Larger capacity:

2-100L, tank 2-1000 cbm, OEM accepted

Work medium:

Liquid Nitrogen, Argon, Oxygen, Natural Gas (LNG), LPG, Ethane, Ethylene, Carbon Dioxide, and other cryogenic gases

Payment:

T/T, L/C, Western union, PayPal etc

Loading port:

Qingdao, Tianjin or Shanghai Port

Global availability:

Americas, Europe, Asia Pacific, Africa etc.

Hotline:

86-13273728386
Cryogenic Liquid Tanks are available in vertical or horizontal orientation for cryogenic service from liquid Oxygen, Nitrogen, Argon, Natural Gas to CO2 temperatures. Models range in size from 3 m3 to 200m3 ( 525 to 52,800 gallons) with pressures up to 25 barg.

We offer a wide range of Cryogenic storage tanks from standard to specialty and custom engineered.


100CBM 0.8Mpa Vertical cryogenic tank

   1.Loading medium: Lo2,Ln2,LAr

   2.Total Volume:105.26m³

       Effective Volume:  100.0 m3

   3.Design pressure: 0.84 MPa

       Working pressure: 0.8 MPa

   4.Overall dimension:Φ3600×15947mm

   5.Outer cylinder design temperature : 60℃

      Inner cylinder design temperature:-196℃

   6.Shell material:Outer jacket: Q245-R;   Inner: S30408.

   7.Insulation: Vacuum powder insulation

   8.Tare weight:  About 34480KG

   9.Filling rate:0.95

   10.Relief Valve:  All valves are high grade Chinese valves.


▌ Product features / Product Overview
Structure features:
1. Double layer structure;
2. Insulation options: Vacuum Insulation or Perlite;
3. Container available design for easy unloading and economic shipment;
4.Tank can equipped with pump, vaporizer, pressure regulator , weighting cell, refrigerator and become a skid-mounted Gas supply unit or Gas filling unit.

Service: Delivering highest quality, standard designs as, individual solutions tailored to the most demanding customer requirements

▌ Apply to industry / For industry
CRYOGENIC TANK CONTAINERS CAN BE USED IN A VARIETY OF INDUSTRIES INCLUDING:
1. Food and beverage
2. Oil and gas field operations
3. Medical
4. Mining
5. Electronics and semiconductor
6. Energy
