LNG Cryogenic Liquid Tank Container pressure vessel Tank
Larger capacity:
2-100L, tank 2-1000 cbm, OEM acceptedWork medium:
Liquid Nitrogen, Argon, Oxygen, Natural Gas (LNG), LPG, Ethane, Ethylene, Carbon Dioxide, and other cryogenic gasesPayment:
T/T, L/C, Western union, PayPal etcLoading port:
Qingdao, Tianjin or Shanghai PortGlobal availability:
Americas, Europe, Asia Pacific, Africa etc.Hotline:
86-13273728386
Cryogenic liquid tanks-also referred to as liquid cylinders are double-walled vacuum vessels with multi-layer insulation in the annular space. They are designed for the reliable and economic transportation and storage of liquefied gases at cryogenic temperatures. The cryogenic products normally found in liquid containers are liquid nitrogen (LIN), liquid argon (LAR), liquid oxygen (LOX) and liquid helium (LHE). Carbon dioxide and nitrous oxide are also available as refrigerated liquids in similar containers.
| Model |
Volume (m3) |
Working Pressure (MPa) | Work medium |
Weight (kg) |
Size (D*H) mm |
| CFL-5 | 5 |
0.8 or 1.6 |
liquid oxygen liquid nitrogen liquid argon |
3412 | 2000*5130 |
| CFL-10 | 10 | 5378 | 2100*7170 | ||
| CFL-15 | 15 | 6415 | 2500*6912 | ||
| CFL-20 | 20 | 8255 | 2500*8765 | ||
| CFL-30 | 30 | 12899 | 2900*8870 | ||
| CFL-50 | 50 | 18960 | 3100*12058 | ||
| CFL-5 | 5 |
2.16 |
liquid carbon dioxide |
4450 | 2000*5130 |
| CFL-10 | 10 | 6986 | 2100*7170 | ||
| CFL-15 | 15 | 8810 | 2500*6912 | ||
| CFL-20 | 20 | 11328 | 2500*8756 | ||
| CFL-30 | 30 | 17961 | 2500*8875 | ||
| CFL-50 | 50 | 26097 | 3200*11300 | ||
| CFL-100 | 100 | 49627 | 3500*16870 |
Delivering highest quality, standard designs as, individual solutions tailored to the most demanding customer requirements
Structure features:
1. This equipment is divided into vertical and horizontal two types.
2. The tanks are equipped with quick-opening manhole thermometer level gauge sight glasses breath hole liquid inlet hole liquid outlet hole CIP washing hole etc.
3. The tank inside and outside surface use precision polishing processing in line with pharmaceutical and food hygiene standard.
Structure features:
1. This equipment is divided into vertical and horizontal two types.
2. The tanks are equipped with quick-opening manhole thermometer level gauge sight glasses breath hole liquid inlet hole liquid outlet hole CIP washing hole etc.
3. The tank inside and outside surface use precision polishing processing in line with pharmaceutical and food hygiene standard.
CRYOGENIC TANK CONTAINERS CAN BE USED IN A VARIETY OF INDUSTRIES INCLUDING:
1. Food and beverage
2. Oil and gas field operations
3. Medical
4. Mining
5. Electronics and semiconductor
6. Energy
1. Food and beverage
2. Oil and gas field operations
3. Medical
4. Mining
5. Electronics and semiconductor
6. Energy
* need writeBuy:LNG Cryogenic Liquid Tank Container pressure vessel Tank
